Laowa 55mm f/2.8 Tilt-Shift 1X Macro (L-Mount)
Launch MSRP
$1,249- Weight
- 1,345g
- Filter
- ⌀77mm
- Min focus
- 0.27m
- Max mag.
- 1.00×
- Formula
- 14E / 11G
- Released
- 2024
Also made for
Specification sheet
Optical construction
- 2x ED
- 1x UHR
- Aperture range
- f/2.8 — f/22
Physical & ergonomics
- Weight
- 1,345g
- ⌀ × length
- 85.0 × 168.5mm
- Filter
- ⌀77mm
- Weather sealed
- No
- Aperture ring
- Yes
Autofocus actuator
- Stabilisation
- Body IBIS
- Teleconverter
- Not supported
- AF speed score
- —
Close-up performance
- Min focus distance
- 0.27m
- Max magnification
- 1.00× (1:1.0)
Optical character
The Laowa 55mm is a tilt-shift lens that also focuses to true 1:1 macro, aimed at product, food and studio still-life work where you want to place the plane of focus precisely at close range. It offers ±10° of tilt and ±12mm of shift, focuses down to 27cm, and the image circle is large enough for GFX medium format with shift reduced to ±8mm.
Tilt and shift each rotate through 90° independently, and the whole lens rotates 360° on its mount, so the movements can be set in any direction. A supplied Arca-Swiss compatible lens support allows parallax-free shift panoramas, the 15-blade aperture keeps out-of-focus highlights round, and the front takes 77mm filters. Focus and aperture are fully manual with no electronic contacts, and at 1,345g and 168.5mm long it is a tripod lens.
Reviewer consensus
We summarise professional reviews only after reading at least two independent ones. Not enough have been published or verified for this lens yet.
Owner sentiment
Owner feedback will appear once we have verified real-world reports for this lens.
Strengths, weaknesses & performance
Strengths
- +Tilt-shift with true 1:1 magnification
- +±10° tilt, ±12mm shift, 360° rotation
- +Tilt and shift rotate independently
- +Lens support for parallax-free shift panoramas
- +77mm filter thread, 15-blade aperture
Weaknesses
- −About 1.35kg and 168.5mm long
- −Heavy vignetting when fully shifted
- −Flare with the sun in or near the frame
- −No electronic contacts or EXIF
Six-axis rating
Ratings are published once at least two independent professional reviews have been read.
Technical specifications
| Mount | L-Mount (FF) · full frame |
|---|---|
| Focal length | 55mm |
| Category | Macro |
| Maximum aperture | f/2.8 |
| Minimum aperture | f/22 |
| Construction | 14 elements in 11 groups |
| Special elements | 2x ED · 1x UHR |
| Aperture blades | 15 |
| Focus type | Manual Focus |
|---|---|
| Drive | Manual Helicoid |
| Minimum focus | 0.27m |
| Max magnification | 1.00× |
| Stabilisation | None (uses body IBIS) |
| Teleconverters | Not supported |
| Weight | 1,345g |
|---|---|
| Diameter × length | 85.0 × 168.5mm |
| Filter thread | ⌀77mm |
| Weather sealing | No |
| Aperture ring | Yes |
| De-clickable aperture | No |
| Release year | 2024 |
| Launch MSRP | $1,249 USD |
Sources
Verified against the pages below. Specifications come from the maker; summaries only reflect reviews and owner reports we actually read.
Specifications
- venuslens.net› product/laowa-55mm-f-2-8-tilt-shift-1x-macro/
- laowa.jp› cat1/55.100mm-ts.html
Launch price
- newsshooter.com› 2024/12/20/laowa-55mm-100mm-f-2-8-tilt-shift-1x-macro-lenses
Professional reviews
- phillipreeve.net› blog/review-laowa-ff-ii-ts-55mm-100mm-f-2-8-macro-1x/
