Viltrox MF 20mm F1.8 ASPH FE
Launch MSRP
$399- Weight
- 775g
- Filter
- ⌀82mm
- Min focus
- 0.25m
- Max mag.
- 0.10×
- Formula
- 12E / 9G
- Released
- 2020
Specification sheet
Optical construction
- 4x ED
- 1x Double-sided Aspherical
- 1x Short-wavelength High-transmittance
- HD Nano Coating
- Aperture range
- f/1.8 — f/16
Physical & ergonomics
- Weight
- 775g
- ⌀ × length
- 76.8 × 102.0mm
- Filter
- ⌀82mm
- Weather sealed
- No
- Aperture ring
- Yes
Autofocus actuator
- Stabilisation
- Body IBIS
- Teleconverter
- Not supported
- AF speed score
- —
Close-up performance
- Min focus distance
- 0.25m
- Max magnification
- 0.10× (1:10.0)
Optical character
Sold in China as the PFU RBMH 20mm F1.8 ASPH, this is Viltrox's all-metal, fully manual wide-angle. It is aimed at night-sky, landscape and interior shooters who want f/1.8 at 20mm and a proper distance scale for a few hundred dollars.
The 12-element design uses four ED elements and a double-sided aspherical element. It has a 14-blade diaphragm, a 148.5° focus throw and an 82mm filter thread. There are no electronic contacts, so the camera records no EXIF data and focus magnification has to be triggered by hand.
Reviewer consensus
Reviewers found the centre sharp from f/1.8 and the frame evening out by f/4 to f/5.6, with soft extreme corners, heavy vignetting and some coma wide open. Distortion is moderate, and colour fringing is reasonably controlled given the price.
Testers like the dense metal build, the damped focus ring and the long, readable distance scale for hyperfocal work. The lack of electronics and the 775g weight are the main criticisms, and flare resistance with bright light sources is only average.
Owner sentiment
Owners call it a good-value astro and travel lens and say the build feels like a much more expensive manual lens. The 82mm filter thread and the hood that stores reversed get positive mentions.
Complaints focus on the weight for a 20mm, missing EXIF data and corner softness wide open. Users who swap between bodies note the focus throw is long for fast street shooting.
Strengths, weaknesses & performance
Strengths
- +f/1.8 at 20mm for a low price
- +All-metal build with long focus throw
- +Clear distance and DoF scales
- +Takes 82mm screw-in filters
- +14-blade aperture
Weaknesses
- −No electronic contacts or EXIF
- −Heavy at 775g
- −Soft corners and strong vignetting wide open
- −Coma visible at f/1.8
Six-axis rating
- Sharpness
- 7.4
- Bokeh Rendering
- 7.2
- Autofocus Speed
- MF
- Flare Resistance
- 6.8
- Build / Sealing
- 8.2
- Value / Size
- 8.2
Editorial 0–10 ratings synthesised from published reviews.
Technical specifications
| Mount | Sony E (FE) · full frame |
|---|---|
| Focal length | 20mm |
| Category | Wide |
| Maximum aperture | f/1.8 |
| Minimum aperture | f/16 |
| Construction | 12 elements in 9 groups |
| Special elements | 4x ED · 1x Double-sided Aspherical · 1x Short-wavelength High-transmittance · HD Nano Coating |
| Aperture blades | 14 |
| Focus type | Manual Focus |
|---|---|
| Drive | Manual Helicoid |
| Minimum focus | 0.25m |
| Max magnification | 0.10× |
| Stabilisation | None (uses body IBIS) |
| Teleconverters | Not supported |
| Weight | 775g |
|---|---|
| Diameter × length | 76.8 × 102.0mm |
| Filter thread | ⌀82mm |
| Weather sealing | No |
| Aperture ring | Yes |
| De-clickable aperture | No |
| Release year | 2020 |
| Launch MSRP | $399 USD |
