Canon RF 28mm F2.8 STM
Launch MSRP
$299- Weight
- 120g
- Filter
- ⌀55mm
- Min focus
- 0.23m
- Max mag.
- 0.17×
- Formula
- 8E / 6G
- Released
- 2023
Specification sheet
Optical construction
- 3x Aspherical
- Aperture range
- f/2.8 — f/22
Physical & ergonomics
- Weight
- 120g
- ⌀ × length
- 69.2 × 24.7mm
- Filter
- ⌀55mm
- Weather sealed
- No
- Aperture ring
- No
Autofocus actuator
- Stabilisation
- Body IBIS
- Teleconverter
- Not supported
- AF speed score
- 7.5 / 10
Close-up performance
- Min focus distance
- 0.23m
- Max magnification
- 0.17× (1:5.9)
Optical character
Canon's first RF pancake and, at its 2023 launch, the smallest RF lens: 24.7mm long and 120g, small enough to make a full-frame EOS R body close to pocketable for street and travel work. Three plastic-moulded aspherical elements, some of them custom-shaped and non-circular, keep the design to 8 elements and hold sharpness well across the frame once in-camera correction has removed the strong native distortion and vignetting.
A single ring switches between manual focus and control functions via a side switch, and a gear-type STM motor drives AF with full-time manual override. The lens supports in-camera focus-breathing correction for video. There is no optical IS or weather sealing, but Canon quotes up to 7 stops of stabilisation on bodies with IBIS. On APS-C bodies it frames like a 45mm normal lens.
Reviewer consensus
Reviewers agree the centre is excellent from f/2.8. One lab measured the outer field as very good to excellent wide open and called it sharper than Canon's larger 24mm and 35mm f/1.8 primes; a real-world test found the edges noticeably softer than the centre, at their best from f/4 to f/11. Lateral colour is low and longitudinal fringing is limited to f/2.8 and f/4. The lens leans heavily on software: raw files show around 4% barrel distortion and more than 3 stops of vignetting at f/2.8, and the camera will not let you switch distortion correction off.
Autofocus is quick and accurate with very little hunting, though the STM hums and manual focus by wire is noisy and the thin ring is fiddly. Bokeh is smoother than expected for a 28mm f/2.8 at close range, but subject isolation is limited. Flare results were mixed, with one test showing rainbow artefacts around the sun and another finding it well controlled. Build is plastic over a metal mount and feels solid for the price.
Owner sentiment
Owners use it as an always-on walk-around lens and like how small it makes bodies from the R50 to the R5. They describe image quality as sharp, clean and well above what the price suggests, with quick, consistent focus, and several say it has become their most-used lens for travel and everyday shooting.
The few reservations are the f/2.8 aperture, which some owners call slow, and its limits for video without extra stabilisation. Few owner reviews report any faults.
Strengths, weaknesses & performance
Strengths
- +Tiny: 24.7mm long, 120g
- +Excellent centre sharpness from f/2.8
- +Low lateral chromatic aberration
- +Supports in-camera breathing correction
- +$299 launch price
Weaknesses
- −f/2.8 limits background blur
- −About 4% raw distortion; correction cannot be disabled
- −Heavy raw vignetting at f/2.8
- −Noisy, fiddly manual focus ring
- −No weather sealing
Six-axis rating
- Sharpness
- 8.4
- Bokeh Rendering
- 6.8
- Autofocus Speed
- 7.5
- Flare Resistance
- 7.2
- Build / Sealing
- 7.2
- Value / Size
- 9.0
Editorial 0–10 ratings synthesised from published reviews.
Technical specifications
| Mount | Canon RF · full frame |
|---|---|
| Focal length | 28mm |
| Category | Wide |
| Maximum aperture | f/2.8 |
| Minimum aperture | f/22 |
| Construction | 8 elements in 6 groups |
| Special elements | 3x Aspherical |
| Aperture blades | 7 |
| Focus type | Autofocus |
|---|---|
| Drive | STM (gear-type) |
| Minimum focus | 0.23m |
| Max magnification | 0.17× |
| Stabilisation | None (uses body IBIS) |
| Teleconverters | Not supported |
| Weight | 120g |
|---|---|
| Diameter × length | 69.2 × 24.7mm |
| Filter thread | ⌀55mm |
| Weather sealing | No |
| Aperture ring | No |
| De-clickable aperture | No |
| Release year | 2023 |
| Launch MSRP | $299 USD |
